Unitree R1-D
The Unitree R1-D is a dual-arm humanoid robot platform launched by Unitree Robotics in April 2026. Starting at $4,290, the R1-D is configurable with 5-DOF (R1-A5) or 7-DOF (R1-A7) robotic arms and offers 15-31 total degrees of freedom. Weighing approximately 11-13 kg (fixed base) or 30-32 kg (mobile wheeled base), the platform is certified for industrial precision assembly tasks with ±0.1mm end-effector accuracy. It features an 8-core high-performance CPU in the body and an 8-core CPU + 10 TOPS AI processor in the head module. Optional NVIDIA Jetson Orin module provides up to 40-100 TOPS AI performance. Environmental perception and voice interaction via RGBD binocular camera (544x448@10Hz), 4-array microphone and dual speakers. A powerful manipulation platform for research labs, industrial automation and educational institutions with fixed base (R1-A5/A7) or mobile wheeled base (R1-A5-D/R1-A7-D) options.
Kurumsal fiyat teklifi için iletişime geçin
Contact us for enterprise pricing
High-Performance Dual-Arm Architecture
Offers 5 DoF per arm in R1-A5 and 7 DoF per arm in R1-A7 configuration. 20-26 total DoF with wide working space and precise manipulation. Waist joint: Yaw±115° Pitch±36°, neck joint: Yaw±115° Pitch±36° movement range.
Advanced Computing and AI Support
8-core high-performance CPU in body, 8-core CPU + 10 TOPS AI in head module. Optional NVIDIA Jetson Orin module provides up to 40-100 TOPS AI performance. RGB and depth map interfaces for visual perception.
Open Platform and Secondary Development
Fully open program interfaces for underlying system, robotic arm, audio, lighting and visual control. Drag-and-drop teaching support. Quick end-effector change capability. OTA software updates.
Flexible Mounting and End-Effector Options
Two mounting types: fixed base or mobile base. Various end-effector options: 2-finger gripper, 3-finger dexterous hand or 5-finger dexterous hand. Hollow + internal wiring for clean and safe cable management.
Versatile Sensing and Interaction
Binocular RGB camera and depth map module (Horizontal 146°, Vertical 124°). Optional wrist camera and chassis LiDAR. 4-array microphone and dual speakers for voice interaction. Safety sensors designed for human-robot collaboration.
Unitree R1-D — Dual-Arm Manipulation Platform Technical Analysis
Mechanical Design and Kinematic Structure
- R1-D is a dual-arm humanoid robot platform offered in 5-DOF (R1-A5) or 7-DOF (R1-A7) configurations. Each arm has the same DoF value and provides a symmetric working envelope.
- The waist joint provides Yaw ±115° and Pitch ±36° movement range for a wide working volume. The neck joint has the same range and optimizes head module environmental perception orientation.
- Hollow + internal wiring design prevents cable entanglement and ensures a safe, clean working environment.
- Crossed roller bearings and deep groove ball bearings achieve high precision and load capacity.
Computing and AI Infrastructure
- 8-core high-performance CPU in the body, 8-core CPU + 10 TOPS AI processing unit in the head module.
- AI processing power can be upgraded to 40-100 TOPS with optional NVIDIA Jetson Orin module, enabling local execution of complex computer vision and deep learning models.
- RGB and depth map interfaces (Horizontal 146°, Vertical 124°) provide real-time 3D perception via the binocular module.
- WiFi 6 and Bluetooth 5.2 support low-latency communication and peripheral sensor integration.
Software and Secondary Development
- Fully open program interfaces for underlying system, robotic arm, audio, lighting and visual control.
- Drag-and-drop teaching support enables intuitive programming of complex tasks.
- OTA (Over-The-Air) update support enables remote software and firmware updates.
- End-effectors can be changed in seconds via quick-change mechanism; options include 2-finger gripper, 3-finger dexterous hand or 5-finger dexterous hand.
Variant Comparison
| Feature | R1-A5 | R1-A7 | R1-A5-D | R1-A7-D |
|---|---|---|---|---|
| Arm DoF | 5 | 7 | 5 | 7 |
| Total DoF | 20 | 26 | 20 | 26 |
| Mobile Base | ❌ | ❌ | ✅ | ✅ |
| Chassis LiDAR | ❌ | ❌ | ✅ | ✅ |
| Wrist Camera | ❌ | ❌ | Ops. | Ops. |
| Weight | ~11 kg | ~13 kg | ~11 kg | ~13 kg |
| Starting price | Kurumsal teklif | Kurumsal teklif | Kurumsal teklif | Kurumsal teklif |
Engineering Evaluation
The Unitree R1-D stands out in the dual-arm humanoid robot segment with its open platform approach and modular structure. The 5-DOF and 7-DOF arm options accommodate different budget and application requirements, while D variants expand the use case with mobile base and advanced sensing. Local AI processing capability is high thanks to NVIDIA Jetson Orin support. Open SDK and drag-and-drop teaching features allow users with limited robotics knowledge to program complex manipulation tasks.
Details & Performance Parameters.
Physical Architecture
Dynamic Performance
Energy & Protection
Computing & Intelligence
Body: 8-Core High-Performance CPU | Head: 8-Core CPU + 10 TOPS | Opt. NVIDIA Jetson Orin (40-100 TOPS)
Binocular RGB Camera + Depth Map | Opt. Wrist Camera | Opt. Chassis LiDAR
Dual-eye computing module + voice interaction system
WiFi 6, Bluetooth 5.2
OTA Updates, Quick End-Effector Change, Drag-and-Drop Teaching, 4-Array Mic + Dual Speakers
Gigabit Ethernet, USB-C, Open Program Interface, End-Effector Connection, WiFi 6, Bluetooth 5.2
Mechanical Components
Low-inertia high-speed inner rotor PMSM
Crossed Roller + Deep Groove Ball bearings
Hollow + Internal Wiring
Fixed base or Mobile base support
Optional 2-finger gripper / 3-finger dexterous hand / 5-finger dexterous hand
Hardware & Materials
The New Intelligence of Operation.
Start your R1-D project with our experts now.
